Ways To Deal With Botnet

A study conducted by Cisco identifies most common detection and mitigation techniques of the Botnet. The study indicates, Botnet creation begins with the download of a software program called a "bot" (for example, IRCBot, SGBot, or AgoBot) along with an embedded exploit (or

payload) by an unsuspecting user, who might click an infected e-mail attachment or download infected files or freeware from peer-to-peer (P2P) networks or malicious Websites.

Once the bot and exploit combination is installed, the infected machine contacts a public server that the botmaster has set up as a control plane to issue commands to the botnet. A common technique is to use public Internet Relay Chat (IRC) servers, but hijacked servers can also issue instructions using Secure HTTP (HTTPS), Simple Mail Transfer Protocol (SMTP), Transmission Control Protocol (TCP), and User Datagram Protocol (UDP) strings. Control planes are not static and are frequently moved to evade detection; they run on machines (and by proxies) that are never owned by the botmaster.

Using the control plane, the botmaster can periodically push out new exploit code to the bots. It can also be used to modify the bot code itself in order to evade signature-based detection or to accommodate new commands and attack vectors.

Initially, however, the botmaster's primary purpose is to recruit additional machines into the botnet. Each zombie machine is instructed to scan for other vulnerable hosts. Each new infected machine joins the botnet and then scans for potential recruits. In a matter of hours, the size of a botnet can grow very large, sometimes comprising millions of PCs on diverse networks around the world.

Botnet Detection and Mitigation

Botnets use multiple attack vectors; no single technology can provide protection against them. For instance, the goal of a DDoS attack is to cripple a server. The goal of a phishing attack is to lure users to a spoofed Website and get them to reveal personal data. The goal of malware can range from collecting personal data on an infected PC to showing ads on it or sending spam from it. A defense-in-depth approach is essential to detect and mitigate the effects of botnets.

Traditional packet filtering, port-based, and signature-based techniques do not effectively mitigate botnets that dynamically and rapidly modify the exploit code and control channel, resort to "port-hopping" (or using standard HTTP/S ports such as 80 and 443), and shuffle the use of zombie hosts.

A variety of open source and commercial tools are currently used for botnet detection. Others use behavioral techniques; for example, building a baseline of a network or system under "normal" conditions and using it to flag abnormal traffic patterns that might indicate a DDoS attack. DNS log analysis and "honeypots" are also used to detect botnets, but these techniques are not always scalable.

The most common detection and mitigation techniques include:

• Flow data monitoring: This technique uses flow-based protocols to get summary network and transport-layer information from network devices. Netflow kind of solutions are  often used by service providers and enterprises to identify command-and-control traffic for compromised workstations or servers that have been subverted and are being remotely controlled as members of botnets used to launch DDoS attacks, perform keystroke logging, and other forms of illicit activity.

• Anomaly detection: While signature-based approaches try to have a signature for every vulnerability, anomaly detection (or behavioral approaches) try to do the opposite. They characterize what normal traffic is like, and then look for deviations. Any burst of scanning activity on the network from zombie machines can be detected and blocked. Anomaly detection can be effectively used on the network as well as on endpoints (such as servers and laptops). On endpoints, suspicious activity and policy violations can be identified and infections prevented.

• DNS log analysis: Botnets often rely on free DNS hosting services to point a subdomain to IRC servers that have been hijacked by the botmaster, and that host the bots and associated exploits. Botnet code often contains hard-coded references to a DNS server, which can be spotted by any DNS log analysis tool. If such services are identified, the entire botnet can be crippled by the DNS server administrator by directing offending subdomains to a dead IP address (a technique known as "null-routing"). While this technique is effective, it is also the hardest to implement since it requires cooperation from third-party hosting providers and name registrars.

• Honeypots: A honeypot is a trap that mimics a legitimate network, resource, or service, but is in fact a self-contained, secure, and monitored area. Its primary goal is to lure and detect malicious attacks and intrusions. Effective more as a surveillance and early warning system, it can also help security researchers understand emerging threats. Due to the difficulty in setup and the active analysis required, the value of honeypots on large-scale networks is rather limited.
